CH-100

AVlinkPro Micro SIP CH-100

A solid state POE powered   micro SIP PBX Bridge Controller,  ideal integration device for managed connectivity to most IP based  video doorbell intercoms and door lock relays.  Designed to enhance residential Intercom features and functions within the Crestron HOME eco-system to enhance premise communications and connectivity. (Also fully functions with Crestron SIMPL windows applications as well as stand-alone usage.)

Introducing the AVlinkPro micro CH-100 . A solid state bridge device that was built for small residential integration and connectivity to help solve the rift in communication and bridge the gap between technologies.

A new unified communications device in the AVlink product line intended to make easy connectivity and more integration options available to create full featured intercom communication within the award winning Crestron Home automation system. CH-100 + will allow for Add on connected Relays (up to 128) and Paging Zone adapters.

Intercom paging and ring tone audio output

Built-in single throw double pole relay

POE Gigabit Lan (powered over ethernet)

jbc420u91-rear-500x500
LP200RNO-02
jbc311u93-din-rail
Works_With_Crestron_Home_V
previous arrow
next arrow
jbc420u91-rear-500x500
LP200RNO-02
jbc311u93-din-rail
Works_With_Crestron_Home_V
previous arrow
next arrow
Product Code: CH-100

Up to 10 device connections! *

* Can be expanded up to 15 end point devices

Call



Now available with the  exciting new SIPAHOY  Crestron Home Intercom  Extension Platform Driver. This  new interface provides  Crestron Home with a  full set of control over  the AVLinkPro intercom  solution.

  • Panel to panel intercom

  • Intercom paging

  • Sound system paging

  • Room Monitoring

  • Call RTSP video sources

  • Utilize 3rd party API’s and triggers

  • Integrate to telephones

  • Works with new XBABBLE Video Softphone for AVLinkPro

For more  details about our  SIPAHOY solution, visit  http://sipahoy.com.

    • Compact Solid State Mini Size (4.29″ x 5.07″ x1.33″)
    • Configure through web interface
    • Provides Video Connectivity through H.323 SIP
    • Full featured Intercom PBX Functions
    • Early video from intercom calls
    • Unicast video to multiple devices
    • Audio Voicemail
    • Audio / Video Paging
    • Touch Screen Panel to Panel Communication
    • Crestron Certified Partner Product
    • Crestron Advanced Auto-Discovery for touch panels
    • Built in Single Throw Double Pole Relay
    • Intelligent Audio Attendant
    • Advanced Crestron Discovery
    • New – Interface API
    • Crestron HOME SIPAHOY Extension capable
    • Analog Audio Output
    • AES67 2 Channel Audio output
    • 1 x LAN 10/100/1000 LAN Port
    • Small form factor
    • POE Powered through Lan Connection

    Specifications:

    Download PDF Specifications


                                       Crestron Home Docs Page



    Dimensions
    Cabinet Size 4.29″ x 5.07″ x1.33″
    Form Factor
    Form Factor MIcro Solid State
    Processor
    Intel Processor Quad Core Embedded
    Power
    Voltage

    5V 2AMP  DC, Class 2 POE device

    SIP Channels
    SIP Channels included 10 Channel
    Power Consumption
    Power Consumption 8 Watts
